Wireline Electric Tubing Cutter 3 1/8″
Wireline deployed electric cutting tool with intelligent control
Wireline deployed electric cutting
tool with intelligent control
Initial Specifications
| OD | 3.125”/ 80mm (Cutter head) |
| Max cut diameter | 6”/ (7.1” *) |
| Min. operating diameter | 3.5”/ 89 mm |
| Max cut thickness | >15.3 mm |
| Pressure rating | 15Kpsi/ 1034 bar |
| Temperature rating | 300F/ 150C |
| Make up length | 93” / 2,8 m |
| Materials | Alu. Bronze & 17/4 PH |
| Weight | 300 lb/ 136 kg |
| Upper tool joint | 1 3/16 GO |
| Lower tool joint | 15/16 SR |
| Max/ operating voltage | 1000/600 V dc |
| Max operating current | 2 A |
